DMX CONTROLLER FOR PROFESSIONAL DIGITAL LED STRIPS
CHLSC27
Available
€79.96
Tax included
DMX CONTROLLER FOR PROFESSIONAL DIGITAL LED STRIPS
DMX controller to use with digital LED strips. It converts the DMX512 signal to SPI (TTL) signal. This controller allows you to control each LED separately via a DMX controller or professional DMX console.
Specification(s):
Specification(s):
- compatible with: [b]digital LED strip[/b] with grey scale IC
- DMX channels: 512
- channel 1: 1st LED red colour
- channel 2: 1st LED blue colour
- channel 3: 1st LED green colour
- channel 4: 2nd LED red colour
- etc:
- DMX or test program selection via DIP switches
- Physical properties
- Number of channels: 512
- Light colour range LED: RGBW
- Number of outputs: 2
- Electrical data
- Maximum current rating: 8 A
- Protection: Overload, Short-circuit
- LED dimmer output type: SPI (TTL)
- Overload protection: No
- Reverse polarity: Yes
- Technical data
- Protocol type: DMX
- Mounting type: Screw, Surface mount
- Dimming curve: Linear
- Set-up options
- Dimming range: 0-100 %
- Driver configuration: DIP switches
- Environmental data
- IP rating: IP20
- Usage location: Indoor only
- Operating temperature: -30-55 °C
- Operational properties
- Instruction manual languages: English
- Restart after protection: No
- Connections
- Wire size: 2.5 mm²
- IT connections
- Connection type: 3-pin XLR
- Power supply
- Input voltage rating VDC: 5-24 V
- Compatibility
- Compatible ICs: WS2811, WS2812, UCS1903, UCS1909, UCS1912, UCS2903, UCS2909, TM1803, TM1804, TM1809, TM1812
- Included
- Power adapter/charger: No
- Product basic info
- Colour: Black
- Additional colour: Green, Red
- Depth: 125 mm
- Height: 40 mm
- Weight: 260 g
- Width: 52 mm
- Material: Metal
- Additional material: ABS
- EAN: 5410329670979
