TOROIDAL TRANSFORMER 225VA 2 x 18V / 2 x 6.25A
22518
Out-of-Stock
€84.95
Tax included
TOROIDAL TRANSFORMER 225VA 2 x 18V / 2 x 6.25A
Specification(s):
- approvals: EN 60742/BS3535
- fuse: 130°C thermal fuse
- voltage: 2 x 18V
- current: 2 x 6.25A
- regulation: 6%
- power: 225VA
- weight: 2.70kg
- Ø: 130mm max.
- height: 56mm max.
- fixing bolt: M8 x 60mm
- nut: M8
- metal washer: Ø92mm
- rubber washer: Ø96mm
- connections: 200mm PVC, 10mm stripped and tinned leads
- primary: 1672 18AWG black - black : 1 x 230V
- secondary: *red - yellow / *blue - grey (* = start)
- primary voltage: 230V / 50Hz
- primary-secondary insulation: 500Vdc
- secondary-secondary insulation: 500Vdc
- insulation category: class A, 105°C
- EAN: 5410329237967
