For intermittent operation of circuits and equipment. Blinking light, video/photo single frame shooting, slide projector control, miniature models.
Specification(s):
Specification(s):
- also available as completely mounted module [product name=WMT136][/product]
- output relay with dry switch-over contact: 3A/24V
- pulse time adjustable: between 0.5 and 5s
- pause time adjustable: between 2.5 and 60s
- power supply: 12Vdc / 100mA
- dimensions: 40 x 85mm / 1.6 x 3.4"
- EAN: 5410329733667
