Constant Current LED Driver - Single Output - 350 mA - 25 W
PLM-25E-350
Available
€26.96
Tax included
Constant Current LED Driver - Single Output - 350 mA - 25 W
PLM-25 is a 25 W economical AC/DC LED power supply series. Incorporating a built-in active PFC design, PLM-25 provides a high power factor value greater than 0.9. In addition, with the low no load power consumption below 0.5 W, and the setup time less than 500ms, PLM-25 is complied with the ERP regulation required by European Union for lighting fixtures.
PLM-25 is a class II (without FG pin) power unit housed with the UL 94V-0 rated flame retardant plastic case. The I/O terminals are designed with screw-less clamp style terminal block that greatly simplifies the wiring installation. Two types of models with different input voltage range are offered: PLM-25 series, which operates from 110-295 VAC, and PLM-25E series, which operates from 180-295 VAC. These two series are both constant current output design, supplying models with the current of 350 mA, 500 mA, 700 mA and 1050 mA, respectively.
Specification(s):
Specification(s):
- 230 VAC only or full range (up to 295 VAC) models available
- built-in active PFC function
- constant current design
- protections: short circuit
- cooling by free air convection
- fully isolated plastic case
- class II power unit, no FG
- class 2 power unit (for PLM-25-500/700/1050)
- no load power consumption <0.5 W
- high reliability, low cost
- Physical properties
- Number of outputs: 1
- Housing type: Enclosed
- Electrical data
- Output current rating: 350 mA
- Output power rating: 25.2 W
- Technical data
- Series: PLM
- Input efficiency: 86 %
- Dimmable: No
- Set-up options
- Dimming type: No dimming
- Environmental data
- IP rating: IP30
- Power supply
- Input current rating: 0.15 A
- Input voltage rating VAC: 180-295 V
- Output voltage rating VDC: 42-72 V
- Technology type: Constant current mode
- Input voltage rating VDC: 254-417 V
- Product basic info
- Colour: White
- Additional colour: Blue
- Depth: 145 mm
- Height: 22 mm
- Weight: 110 g
- Width: 38 mm
- EAN: 8720207879736
