4 MP IR FIXED NETWORK TURRET CAMERA (IP)- VARIFOCAL - WHITE

ECAMIP501
Available
€179.01
Tax included
4 MP IR FIXED NETWORK TURRET CAMERA (IP)- VARIFOCAL - WHITE


4 megapixel IP indoor/outdoor turret-type camera. [b]Very sensitive at low light (up to colour: 0.005 lux )[/b], which allows you to have colour images at very dark conditions. The camera has powerful IR LEDs built-in for night surveillance up to 30 meter. With the powerful motorized varifocal lens you can effortlessly approach any object. With its true [b]120 dB Wide Dynamic Range (WDR) [/b]technology, perfect image quality is guaranteed even with high backlight. Optimal compression supporting H.265+. With no difficult IP setup and only one cable for power and data, the PoE feature connects cameras and NVRs quickly and easily. A built-in TF-card slot allows you to record video on a local SD-card.

Specification(s):
  • [b]camera with solid premium aluminium base and plastic decorative ring[/b]
  • 1/3" progressive scan CMOS
  • 2560 x 1440 @20 fps
  • 2.8 mm to 12 mm varifocal lens (motorized)
  • H. 265+ / H. 265 / H. 264+ / H. 264 video formats
  • up to 30 m IR range
  • IP67
  • BLC / 3D DNR / ROI
  • true wide dynamic range (120 dB WDR)
  • built-in micro SD/SDHC/SDXC card slot, up to 265 GB
  • various applications
  • Android app: [link url=https://play.google.com/store/apps/details?id=com.mcu.guardingvision&hl=nl&gl=US]Guarding Vision[/link]
  • iOS app: [link url=https://apps.apple.com/us/app/guarding-vision/id1101697283#?platform=iphone]Guarding Vision[/link]
  • Windows software: [link url=https://www.velleman.eu/support/downloads/?code=ENVR104]Guarding Vision[/link]
  • iOS software: [link url=https://www.velleman.eu/support/downloads/?code=ENVR104]Guarding Vision[/link]
Feature(s):
  • camera:
  • image sensor: 1/3" progressive scan CMOS
  • min. illumination: colour: 0.005 lux @ F1.6 (AGC on)
  • shutter speed: 1/3 s - 1/100,000 s, slow shutter support
  • slow shutter: yes
  • auto-iris: no
  • day & night: IR cut filter
  • digital noise reduction: 3D DNR
  • WDR (Wide Dynamic Range): 120 dB true WDR
  • angle adjustment: pan: 0° - 355°, tilt: 0° - 70°, rotation: 0° - 355°
  • lens:
  • focal length: 2.8 mm to 12 mm varifocal lens
  • aperture: F1.6
  • focus: V: manual; Z: auto
  • field of view: horizontal: 102° - 31°; vertical: 54° - 17°; diagonal: 123° - 35°
  • lens mount: Ø14
  • IR:
  • max. IR range: 30 m
  • wavelength: 850 nm
  • compression standard:
  • video compression: main stream: H. 265 / H. 264: sub stream: H. 265 / H. 264 / MJPEG
  • H.264 type: main profile / high profile / baseline profile
  • H. 264+: main stream support
  • H. 265 type: main profile
  • H. 265+: main stream support
  • video bit rate: 32 kbps - 8 Mbps
  • smart feature set
  • region of interest: 1 fixed region for main stream and sub-stream
  • image:
  • max. resolution: 2560 x 1440
  • main stream: 50 Hz: 20 fps (2560 x 1440)
  • max. frame rate: 60 Hz: 30 fps (1920 x 1080, 1280 x 720)
  • sub-stream: 50 Hz: 25 fps (1280 x 720, 640 x 480, 640 x 360)
  • max. frame rate: 60 Hz: 30 fps (1280 x 720, 640 x 480, 640 x 360)
  • image enhancement: BLC, 3D DNR
  • image settings: saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
  • day/night switch: auto/scheduled
  • network:
  • network storage: supports micro SD/SDHC/SDXC card, up to 265 GB local storage and ANR
  • alarm trigger: motion detection, video tampering alarm, illegal login
  • protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802,1X, QoS, IPv6, UDP, Bonjour
  • general functions: one-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark
  • API: ONVIF (PROFILE S, PROFILE G), ISAPI
  • simultaneous live view: up to 6 channels
  • user/host: up to 32 users; 3 levels: Administrator - Operator - User
  • web browser: IE10+, Chrome 57.0+, Firefox 52.0+
  • interface:
  • network interface: 1 RJ45 10/100 Mbps self-adaptive Ethernet port
  • general:
  • operating conditions: -30 °C - 60 °C (-22 °F - 140 °F), humidity 95 % or less (non-condensing)
  • power supply: 12 VDC ± 20%, 5.5 mm coaxial power plug; PoE (802.3af, class 3)
  • power consumption and current: Z: 12 VDC, 0.75 A, max: 10 W; PoE: (802.3af, 36 V-57 V), 0.27 A-0.17 A, max: 10 W
  • IP rating: IP67
  • material: metal
  • dimensions: Ø 127 mm x 96 mm (Ø 5" x 3.78")
  • weight: 560 g (1.2 lb.)


  • EAN: 5410329736279
