VERTICAL RELAY 10A/30VDC-220VAC 1 x INVERTER 6Vdc
VERTICAL RELAY 10A/30VDC-220VAC 1 x INVERTER 6Vdc
VERTICAL RELAY 10A/30VDC-220VAC 1 x INVERTER 6Vdc
VERTICAL RELAY 10A/30VDC-220VAC 1 x INVERTER 6Vdc

VERTICAL RELAY 10A/30VDC-220VAC 1 x INVERTER 6Vdc

VR10V061C
Out-of-Stock
€4.44
Tax included
VERTICAL RELAY 10A/30VDC-220VAC 1 x INVERTER 6Vdc


Specification(s):
  • heavy-duty switching power up to 2200VA
  • compact size allows mounting in a confined space
Feature(s):
  • Physical properties
  • Intern contact material: Silver cadmium oxide (AgCdO)
  • Number of inverters: 1
  • Electrical data
  • Maximum switching voltage rating VAC: 220 V
  • Switching current rating VDC: 10 A
  • Dielectric strength frequency rating: 50 Hz
  • Dielectric strength voltage rating VAC: 1000 V
  • Coil voltage rating VDC: 6 V
  • Coil resistance: 68 ohm
  • Maximum switching current rating VAC: 10 A
  • Technical data
  • Mounting type: PCB
  • Nominal operating power: 0.56 W
  • Type: Vertical relay
  • Environmental data
  • Operating temperature: -40-70 °C
  • Operational properties
  • Contact type: Inverter
  • Product basic info
  • Colour: Transparent
  • Depth: 1.21 cm
  • Height: 2.94 cm
  • Weight: 15.5 g
  • Width: 2.83 cm
  • Material: ABS


  • EAN: 5410329292744
