POLYCRYSTALLINE SOLAR PANEL 10 W 12 V


Robust all-purpose solar module with high efficiency solar cell.

Specification(s):
  • high module efficiency and stable power output based on leading process technology
  • outstanding electrical performance under high temperature conditions or low rradiance conditions.
  • easy of installation and all-weather applications
  • for: small solar installations (caravan, camper...)
Feature(s):
  • maximum power (Pmax): 10 W
  • voltage at Pmax (Vmp): 17.6 V
  • current at Pmax (Imp): 0.58 A
  • open-circuit voltage (Voc): 21.8 V
  • short-circuit current (Isc): 0.61 A
  • temperature coefficient of Voc: -(0.40 ± 0.05) % / °C
  • temperature coefficient of Isc: -(0.065 ± 0.01) % / °C
  • temperature coefficient of power: -(0.5 ± 0.05) % / °C
  • NOCT: 47 ± 2 °C
  • operating temperature: -40 °C to +85 °C
  • maximum system voltage: 600 VDC
  • power tolerance: ± 3 %
  • cells: polycrystalline silicon solar cell
  • number of cells and connections: 36 (4 X 9)
  • module dimension: 356 mm x 253 mm x 30 mm
  • weight: 1.16 kg (2.56 lbs)


  • EAN: 5410329670726
