SOLAR FLEXIBLE PANEL 12 V 100 W
SOLAR FLEXIBLE PANEL 12 V 100 W
SOLAR FLEXIBLE PANEL 12 V 100 W
SOLAR FLEXIBLE PANEL 12 V 100 W

SOLAR FLEXIBLE PANEL 12 V 100 W

SOL100F
Available
€379.01
Tax included
SOLAR FLEXIBLE PANEL 12 V 100 W


High Efficiency, High Quality PV Module.

Specification(s):
  • high module efficiency and stable power output based on leading process technology
  • outstanding electrical performance under high temperature conditions or low radiance conditions
  • easy of installation and all-weather applications
  • peak power of single module is guaranteed in ± 3% power tolerance
  • strong framed module, passing load test of 5400 Pa ( IEC61215 2nd)
Feature(s):
  • maximum power (Pmax): 100 W
  • voltage at Pmax (Vmp): 17.6 V
  • current at Pmax (Imp): 5.72 A
  • open-circuit voltage (Voc): 21.1 V
  • short-circuit current (Isc): 6.30 A
  • temperature coefficient of Voc: (0.065 ± 0.015) % / °C
  • temperature coefficient of Isc: -(80 ± 10) mV % / °C
  • temperature coefficient of power: -(0.5 ± 0.05) % / °C
  • NOCT: 47 ± 2 °C
  • operating temperature: -40 °C to +85 °C
  • maximum system voltage: 600 V DC
  • power tolerance: ± 5 %
  • cells: multicrystalline silicon solar cell
  • number of cells and connections: 32 (4 x 8)
  • module dimension: 1150 mm x 535 mm x 3 mm (1.12")
  • weight: 2.2 kg (7.68 lbs)


  • EAN: 5410329694548
