Wiha digital multimeter up to 600 VAC - CAT IV (45218)

[youtube]KR0-UyhdWnc[/youtube] Are you looking for a multimeter that covers the relevant measurement variables needed during the workday of an electrician? The digital multimeter from Wiha optimally equips you for a wide variety of measurements. This single tool can be used to make voltage, current, resistance, frequency, capacity, and temperature measurements. In addition, continuity and diode tests are also possible. A large LCD display makes the measurement results immediately readable even beyond the measurement process. An additional signal sound indicates the current flow during the continuity check. Thanks to the automatic measuring range selection, the manual pre-selection of specific measurement ranges is no longer required. The relative value measurement offers another advantage. The storage of previous measurement values and their comparison to future measurement results allows a variety of control options. According to the measurement categories CAT III up to 600 V and CAT IV up to 300 V, the digital multimeter from Wiha offers maximum safety for working on building installations and directly on the sources of low-voltage installations. EN 61010-1, EN 61010-2-033, EN 61010-031.

Specification(s):

• Increases your efficiency: All relevant measurement functions in a single measuring device.
• Makes handling easier: Automatic measuring range setting saves the manual pre-selection.
• Simplifies your work: Simplifies storage and relative value measurement and expedites the comparison of measured values.
• Application: For multi-functional use in different application locations.
• Standard: CE and GS certified.

Feature(s):

• Physical properties
• Backlight: No
• Maximum digits display: 4
• Display type: LCD
• Electrical data
• AC current measurements: 10 A, 40 mA
• AC voltage measurements: 0-600 V
• Audible continuity measurement: Yes
• Automatic polarity indication: Yes
• Capacity measurements: 100 nF
• DC current measurements: 10 A, 40 mA
• DC voltage measurements: 0-600 V
• Diode test: Yes
• Diode test specifications:

  up to 2 V

• Frequency measurements: 5 MHz
• Fuse type: F 0.4 A / 600 V, ceramic 6.3 x 32 mm, F 10 A / 600 V, ceramic 6.3 x 32 mm
• Resistance measurements: 40 MOhm
• True RMS: No
• Continuity test: Yes
• Continuity test specifications:

  < 30 ohm

• Technical data
• Pollution degree: 2
• Data-hold function: Yes
• Safety rating: CAT III / 600 V, CAT IV / 300 V
• Voltage tester type: AC/DC
• Automatic power-off function: Yes
• Safety standard: EN 61010-031, EN 61010-1, EN 61010-2-033
• Relative value measurement: Yes
• Remote voltage test: Yes
• Environmental data
• IP rating: IP40
• Usage location: Indoor & outdoor
• Operating temperature °C: 0-50 °C
• Storage temperature °C: -10-50 °C
• Operational properties
• Instruction manual languages: Dutch, English, French, German, Italian, Polish, Spanish, Swedish
• Temperature measuring range °C: -20-500 °C
• Range setting: Automatic
• Power supply
• Number of batteries: 2
• Batteries: Yes
• Battery IEC size: AAA (LR03, R03, FR03, HR03, KR03, ZR03 ,24A, 24D, 24LF, UM4, Micro, MN2400, MX2400, MV2400)
• Battery composition: Alkaline
• Low-battery indicator: Yes
• Included
• Set contents:

  test leads

• Product basic info
• Colour: Red
• Additional colour: Yellow
• Depth: 45 mm
• Height: 150 mm
• Weight: 220 g
• Width: 80 mm
• Material: ABS

• EAN: 4010995452186
