VTSSD4
Out-of-Stock
€899.01
Tax included
MULTI-FUNCTION SMD REWORK STATION 100 W / 600 W


Specification(s):
  • soldering
  • isolated power supply: high-quality 32 Vac transformer designed for lead-free soldering/desoldering
  • temperature stability: tip temperature accurate to within ± 3 °C (6 °F)
  • desoldering
  • vacuum switch: suction is controlled by a finger-actuated thyristor circuit conveniently located on the desoldering handle
  • SMD rework
  • hot air function: 600 W heating element
  • energy saving mode
  • available options:
  • spare desoldering tips:
  • 1.2 mm: [product name=BITDEST2]BITDEST2[/product] (standard desoldering tip)
  • 1.0 mm: [product name=BITDEST3]BITDEST3[/product]
  • 1.5 mm: [product name=BITDEST4]BITDEST4[/product]
  • spare filter: [product name=FILT/DES2]FILT/DES2[/product]
  • spare soldering bits:
  • 0.2 mm: [product name=BITSSC1]BITSSC1[/product]
  • 0.5 mm: [product name=BITSSC2]BITSSC2[/product]
  • spare desoldering iron: [product name=VTSSD3/DESOL]VTSSD3/DESOL[/product]
  • spare soldering iron: [product name=VTSSC7/SP5]VTSSC7/SP5[/product]
  • spare cleaning pin: [product name=VTSSD/SP2]VTSSD/SP2[/product]
  • barrel and nut assembly for soldering iron: [product name=VTSSC7/SP4]VTSSC7/SP4[/product]
  • barrel and nut assembly for desoldering iron: [product name=VTSSD3/SP2]VTSSD3/SP2[/product]
  • desoldering iron heater: [product name=VTSSD3/SP1]VTSSD3/SP1[/product]
Feature(s):
  • Electrical data
  • Maximum power consumption: 900 W
  • Power rating desoldering: 100 W
  • Power rating soldering: 100 W
  • Technical data
  • Airflow rate: 1.5-40 l/min
  • Set-up options
  • Temperature range desoldering: 300-450 °C
  • Temperature range SMD rework: 100-480 °C
  • Temperature range soldering: 150-480 °C
  • Adjustable temperature control: Yes
  • Operational properties
  • Lead-free soldering/desoldering: Yes
  • Soldering/desoldering usage: Desoldering
  • Power supply
  • Input frequency rating: 50 Hz
  • Input voltage rating VAC: 220-240 V
  • Voltage rating soldering iron: 32 V
  • Voltage rating desoldering: 32 V
  • Voltage rating SMD rework: 230 V
  • Product basic info
  • Colour: Black
  • Additional colour: White
  • Depth: 36.5 cm
  • Height: 30 cm
  • Weight: 12 g
  • Width: 15 cm
  • Material: Aluminium


  • EAN: 5410329588366
