WPSH212
Available
€9.91
Tax included
SENSOR SHIELD FOR ARDUINO® ATMEGA


This I2C 3V3 sensor shield for Arduino Mega works perfectly together with the [product name=WPSH412][/product] and it enables you to add up to 8 sensors with easily accessible connectors. Picture this; you just added a [product name=WPSH412][/product] to your Arduino Mega and you want to add sensors to the I2C bus. However, the 3V3 connection is stuck underneath the TFT shield and you need logic converters to add a 3V3 sensor to a 5V I2C bus. Look no further, this sensor shield will help you out!

Specification(s):
  • 4 x 3V3 outputs
  • 1 x 5V output
  • built-in logic converter (3V3 sensor to 5V I2C bus)
  • add up to 3 I2C sensors via dedicated ports
  • 2 x interrupt pins (I18 & I19, also connected through logic convertor)
  • easy access to five analog sensors: A11, A12, A13, A14, A15
  • built-in buzzer (pin A10)
  • fits perfectly together with the [product name=WPSH412][/product]
Feature(s):
  • supply voltage: 5V
  • length: 57 mm
  • width: 26.2 mm
  • height: 13.4 mm
  • weight: 9.55 g


  • EAN: 5410329730666
