VR17V121C
Available
€3.91
Tax included
POWER RELAY 17A 12VDC COIL 1C - INRUSH 110A


Specification(s):
  • very high inrush current (110A)
  • suitable for switching power up to 2880VA
Feature(s):
  • Physical properties
  • Intern contact material: Silver nickel (AgNi), Silver tin oxide(AgSnO)
  • Electrical data
  • Dielectric strength voltage rating VAC (between contact and coil): 5000 V
  • Switching current rating VDC: 17 A
  • Coil voltage rating VDC: 12 V
  • Coil resistance: 272 ohm
  • Dielectric strength voltage rating VAC (between open contact): 1000 V
  • Inrush current rating: 110 A
  • Technical data
  • Mounting type: PCB
  • Nominal operating power: 0.53 W
  • Type: Power relay
  • Environmental data
  • Operating temperature: -40-70 °C
  • Operational properties
  • Contact type: SPDT
  • Product basic info
  • Colour: Black
  • Depth: 1.2 cm
  • Height: 2 cm
  • Weight: 13 g
  • Width: 2.8 cm
  • Material: ABS


  • EAN: 5410329435783
