High Efficiency, High Quality PV Module.
Specification(s):
Specification(s):
- high module efficiency and stable power output based on leading process technology
- outstanding electrical performance under high temperature conditions or low radiance conditions
- easy of installation and all-weather applications
- peak power of single module is guaranteed in ± 3% power tolerance
- strong framed module, passing load test of 5400 Pa ( IEC61215 2nd)
- maximum power (Pmax): 50 W
- voltage at Pmax (Vmp): 17.6 V
- current at Pmax (Imp): 2.86 A
- open-circuit voltage (Voc): 21.1 V
- short-circuit current (Isc): 3.15 A
- temperature coefficient of Voc: (0.065 ± 0.015) % / °C
- temperature coefficient of Isc: -(80 ± 10) mV % / °C
- temperature coefficient of power: -(0.5 ± 0.05) % / °C
- NOCT: 47 ± 2 °C
- operating temperature: -40 °C to +85 °C
- maximum system voltage: 600 VDC
- power tolerance: ± 5 %
- cells: multicrystaline silicon solar cell
- number of cells and connections: 32 (4 x 8)
- module dimension: 645 mm x 535 mm x 3 mm (0.12")
- weight: 1.6 kg (3.56 lbs)
- EAN: 5410329694531
