CERMET TRIMMER SINGLE-TURN 1K
CERMET TRIMMER SINGLE-TURN 1K
CERMET TRIMMER SINGLE-TURN 1K
CERMET TRIMMER SINGLE-TURN 1K

CERMET TRIMMER SINGLE-TURN 1K

K001SL
Available
€2.20
Tax included
CERMET TRIMMER SINGLE-TURN 1K


10mm square single-turn trim potentiometers. The cermet technology ensures stability and reliability. These PCB-mounted trimmers are available in different versions, requiring the user to adjust the trimmer either from the top or from the side. All components are sealed to withstand PCB washing solvents.

Specification(s):
  • CITEC 4295L
  • vertical mounting
  • horizontal adjustment
  • pin layout: line
  • range: 10E to 2M (E3 series)
Feature(s):
  • power rating: 0.5W at 70°C
  • temperature range: -55°C to +125°C
  • tolerance: ±10%
  • working voltage: 500Vdc
  • rotation:
  • electrical: 260°
  • mechanical: 300°


  • EAN: 5410329338091
