CERMET TRIMMER MULTI-TURN 1K
K001TY
Niet op voorraad
€ 2,52
Inclusief belasting
CERMET TRIMMER MULTI-TURN 1K
Professional multiturn trimming potentiometers.
The cermet resistance element offers stability and high resolution. The trimmer is actuated by a screw with a slipping clutch at each end of travel. End stops are marked by an audible click. All units have a blue plastic case which withstands all recognised board washing solvents.
Specificatie(s):
Specificatie(s):
- MEC CITEC 4290Y
- vertical mounting
- vertical adjustment
- pin layout: triangle
- bereik: 100E to 1M (E3 series)
- vermogen: 0.5W at 70°C
- tolerantie: ±10%
- working voltage: 300Vdc max.
- rotatie:
- elektrisch circuit: 22 turns nom.
- mechanisch: 25 turns nom.
- EAN:
